Home /Products/Kevlar Aramid Rope/High Strength Kevlar Aramid Rope 1000lbs Tensile Strength Kevlar Aramid Yarn

High Strength Kevlar Aramid Rope 1000lbs Tensile Strength Kevlar Aramid Yarn

1 roll
MOQ
USD 350
Price
High Strength Kevlar Aramid Rope 1000lbs Tensile Strength Kevlar Aramid Yarn
Features Gallery Product Description Chat Now
Features
Specifications
Water Absorption: Low
Material: Kevlar Aramid
Melting Point: 500°C
Diameter: 3mm
Length: 100ft
Color: Yellow
Uv Resistance: Yes
Heat Resistance: Yes
Tensile Strength: 1000lbs
Applications: Marine, Industrial, Outdoor
Stretch: Minimal
Weight: 1.5lbs
Flexibility: High
Chemical Resistance: Yes
Abrasion Resistance: Yes
Highlight:

High Strength Kevlar Aramid Rope

,

Kevlar Aramid Rope 1000lbs

,

1000lbs Kevlar Aramid Yarn
Basic Infomation
Place of Origin: China
Brand Name: Vibran
Model Number: VB-AR
Payment & Shipping Terms
Packaging Details: Carton
Delivery Time: within 5 days
Payment Terms: T/T,Western Union,MoneyGram
Supply Ability: 5000 Rolls per day
Product Description
Kevlar Aramid Rope for Glass Tempering Furnace - High Temperature Resistant
Our Kevlar aramid rope is a high-performance transmission and load-bearing component specifically designed for glass tempering furnaces. Crafted with premium Kevlar aramid fiber as the core material, it integrates exceptional heat resistance, tensile strength, and durability, perfectly adapting to the high-temperature, high-load working environment of glass tempering equipment.
High Strength Kevlar Aramid Rope 1000lbs Tensile Strength Kevlar Aramid Yarn 0
Core Features
  • Outstanding High-Temperature Resistance: Withstands continuous operating temperatures up to 260°C and short-term exposure to higher temperatures.
  • Superior Tensile Strength: Reinforced with high-strength Kevlar aramid fiber, boasting excellent load-bearing capacity.
  • Exceptional Durability & Wear Resistance: Features strong abrasion resistance and fatigue resistance for long-term use.
  • Stable Performance & Low Maintenance: Maintains stable dimensional stability in harsh conditions, reducing maintenance costs.
  • Corrosion & Chemical Resistance: Resists erosion from common industrial chemicals, moisture, and humidity.
Product Specifications
Item Specification
Material 100% Kevlar Aramid Fiber
Continuous Operating Temperature -50°C ~ 260°C
Short-Term Peak Temperature Up to 300°C
Diameter Range 2mm - 20mm (Customizable)
Standard Length 250m/roll, 500m/roll (Custom lengths available)
Color Standard: Yellow (Custom colors for bulk orders)
Braiding Structure 8-strand, 12-strand (Customizable)
Tensile Strength ≥ 2800 N/mm²
Elongation at Break ≤ 3.5%
Wear Resistance Excellent (Passes 5000+ hours of friction testing)
Chemical Resistance Resists acids, alkalis, and common industrial solvents

Flat Rope Size   (Can be customized)

Model

Width (mm)

Thickness (mm)

8 x 3

8

3

8 x 4

8

4

10 x 3

10

3

10 x 4

10

4

10 x 5

10

5

12 x 3

12

3

12 x 3.5

12

3.5

12 x 4

12

4

12 x 4.5

12

4.5

12 x 5

12

5

12 x 5.5

12

5.5

13 x 2

13

2

13 x 3

13

3

13 x 3.5

13

3.5

Square Rope Size   (Can be customized)

Model

Width (mm)

Thickness (mm)

4 x 4

4

4

5 x 5

5

5

5.5 x 5.5

5.5

5.5

6 x 6

6

6

8 x 8

8

8

10 x 10

10

10

12 x 12

12

12

Round Rope Size   (Can be customized)

Dia 2mm

Dia 3mm

Dia 4mm

Dia 5mm

Dia 6mm

Dia 8mm

Dia 10mm

Dia 12mm

Dia 20mm
Application Scenarios
Specialized for glass tempering furnaces, including flat glass tempering furnaces, curved glass tempering furnaces, and ultra-thin glass tempering equipment. Widely used in transmission systems, load-bearing mechanisms, and guiding components of tempering furnaces.
Why Choose Our Kevlar Aramid Rope?
  • Equipment-Specific Design: Tailored to the working characteristics of glass tempering furnaces.
  • Premium Material Selection: High-quality Kevlar aramid fiber from reputable suppliers.
  • Customization Support: Flexible customization of diameter, length, and structure.
  • Strict Quality Control: Rigorous testing for tensile strength, heat resistance, and wear resistance.
Installation & Usage Notes
  • Pre-Installation Check: Inspect the rope for any damage before installation.
  • Proper Tensioning: Maintain moderate tension to prevent breakage or slippage.
  • High-Temperature Protection: Do not expose to temperatures exceeding 300°C for extended periods.
  • Avoid Sharp Edges: Ensure the rope contacts smooth surfaces only.
  • Regular Inspection: Check monthly for wear, elongation, or deformation.
  • Storage Conditions: Store in a dry, cool, and well-ventilated area.
Packing and Shipping
The Kevlar Aramid Ropes are packed in strong, durable cardboard boxes with a protective inner lining. The boxes are clearly labeled with the product name and specifications. For shipping, the boxes are securely wrapped in plastic and placed in sturdy wooden crates.
High Strength Kevlar Aramid Rope 1000lbs Tensile Strength Kevlar Aramid Yarn 1 High Strength Kevlar Aramid Rope 1000lbs Tensile Strength Kevlar Aramid Yarn 2 High Strength Kevlar Aramid Rope 1000lbs Tensile Strength Kevlar Aramid Yarn 3
